This product has additional required/recommended options. To configure, add to your cart.
- Rear Mounting Bracket Recommended
- Drawer slides are rated for 100 pounds at full extension
- Mounts to the side of the drawer for stability and strength
- Provides easy access to drawer with full extension slides
- Lever disconnect allows easy and quick removal of the drawer from the cabinet members
- Designed to be installed on panel frameless cabinets
- All Hardware Resources cabinet hardware comes with a limited lifetime warranty
- Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
- Drawer Length: 22"
- Slide Length: 22"
- Extension Type: Full Extension
- Slide Type: Ball Bearing
- Weight Capacity: 100 lbs
- Minimum Cabinet Depth: 22"
- Material: Steel
- Quantity: 2
- Quantity: 1
- 303FU10-R: 10 Inch Drawer Slide
- 303FU12-R: 12 Inch Drawer Slide
- 303FU14-R: 14 Inch Drawer Slide
- 303FU16-R: 16 Inch Drawer Slide
- 303FU18-R: 18 Inch Drawer Slide
- 303FU20-R: 20 Inch Drawer Slide
- 303FU22-R (This Model): 22 Inch Drawer Slide
- 303FU24-R: 24 Inch Drawer Slide
This product is listed under the following manufacturer number(s):
